Analog Inputs 4 female NEUTRIK™ XLR electronically balanced / RF filtered
> 40kΩ Impedance
+20dBu maximum input level with ESS™ Hyperstream® II 120dB dynamic range 32-bit A/D converters
Digital Inputs 2 stereo AES/EBU
Analog Outputs 8 male NEUTRIK™ XLR  electronically balanced / RF filtered
120Ω Impedance
+20dBu maximum output level with ESS™ Hyperstream® IV 120dB dynamic range 32-bit D/A converters
Connectivity 100MB RJ45 Ethernet interface compatible with common TCP/IP network equipment
System Performance 96kHz sampling rate, 64-bit accumulators
Frequency response of 20~20k Hz at -0.5dB
THD+N lower than 0.003% at +4dBu, 1khz, 0dB input
Interchannel crosstalk >100dB
Cooling Low noise and long life SUNON™ Maglev™ fan
Power 90~264Vac / 50-60Hz / 25W max consumption (industrial grade power supply)
Size (WxHxD) 482×44.5x210mm net, 550x110x250mm gross
Weight 2.7kg net, 4.2kg gross
