Power supply Switch mode with active PFC (Universal AC input from 90 to 260V)
Output stage  Proprietary High-Speed High-Current 4 generation discrete Class D
Model SLQ4800
RMS Output Power (1kHz, 1% THD, EIA standard) 4x 800W / 8Ω
4x 1200W / 4Ω
4x 1200W / 2Ω
Working modes Stereo, Parallel, Bridge
Frequency response 5~20,000Hz (-1dB)
Typical THD (1W, 20Hz~20kHz, 8Ω / 300W, 1kHz, 8Ω ) <0.01%  /  <0.05%
Signal to Noise Ratio 110dB(A)
Crosstalk (1kHz) >75dB
Input Impedance 20 kΩ (Balanced)
Maximum input  +20dBu
Amplifier slew rate >50V/us
Amplifier damping factor (8 ohms, 500Hz) >2500 (internal)
Preamp  Ultra low distortion opamps with audiophile MUSE Fine Gold capacitors
Nominal Voltage Gain  x50 (34dB) on all models
Cooling  Temperature regulated long life brush-less fans, front to back airflow
Protections  Short-circuit, Over and Under-voltage, Over-current, Over-load, Temperature
Input connectors  4 Balanced REAN XLR
Output connectors  4 LockOn REAN RLS4MP
Power connector  IEC C14 with locking latch
Operating Voltage  90~260V AC
Size (WxHxD) 482x45x242mm
Weight 4.5kg net
6kg gross

Downloads

CELTO_SL_SERIES
